EcoPower ECP-7000 30x30x10mm High Speed HV Cooling Fan — 21,000 RPM

The EcoPower ECP-7000 30x30x10mm High Speed HV Cooling Fan is a high-voltage compatible cooling fan designed to keep ESC and motor temperatures in check on 1/12, 1/10, and 1/8 scale RC platforms. Running at 21,000 RPM on 5V–8.75V (compatible with 2S HV LiPo systems), the ECP-7000 delivers effective airflow in a compact 30mm form factor with a standard 24x24mm mounting pattern and 2-pin JST connector. Note: install at least 5mm away from the motor to allow sufficient airflow and prevent magnet interference.

Key Features

• Part Number: ECP-7000
• Fan Speed: 21,000 RPM
• Dimensions: 31 x 31 x 10.5mm
• Mounting Pattern: 24 x 24mm
• Operating Voltage: 5V – 8.75V (compatible with 2S HV LiPo)
• Current Draw: 0.45A
• Connector: 2-pin JST
• Material: Plastic
• Weight: ~10g
• Suitable for 1/12, 1/10, and 1/8 scale ESC and motor applications

Installation Note

Install at least 5mm away from the motor to allow sufficient airflow and prevent magnet interference with fan operation.

Compatibility

• 1/12, 1/10, and 1/8 scale RC platforms
• Compatible with 2S HV LiPo systems (8.75V max)
• Standard 24x24mm mounting pattern fits most ESC and motor fan mounts
• 2-pin JST connector — verify connector compatibility with your ESC or motor before purchasing

Benefits

• 21,000 RPM delivers high airflow in a compact 30mm package
• HV compatible — runs directly on 2S HV LiPo voltage without a separate regulator
• Standard 24x24mm mount fits most 1/10 and 1/8 scale ESC and motor fan mounts
• Lightweight at ~10g — minimal impact on vehicle weight
• Low current draw (0.45A) minimizes impact on ESC power output

Quick Take

Need to keep your ESC or motor temps under control? The EcoPower ECP-7000 runs at 21,000 RPM on HV LiPo voltage, fits a standard 24x24mm mount, and connects via 2-pin JST — compact, lightweight, and ready to install.
